Recording: D1: NTSC 720x480/PAL: 720x576
Video out x1
Audio input x1/output x1
Storage: 2.5" SATA HDD x1, SD card x1
Backup: USB flash
Record quality: super/high/normal/low
Record mode: always record/automatic SD recording when HDD crash
Playback mode: time search/even list/quick search
Event type: power on/power off/video loss/alarm in-out
RTC: battery built-in
Alarm/Relay: 8 alarm in/2 relay out
Support RS-485
Support 3.75G built-in or USB dongle
GPS built-in
G-Sensor built-in (12 position)
TPMS: RF tire pressure sensor detection
PTZ protocol: support PELCO-P/PELCO-D
User password/HDD format password
Display settings: channel/car number/time/speed/temperature
Multi-language
Power supply: DC 9-36V
Fan built-in
Power out: 12V DC 1.5A controlled by ACC power
Power consumption: 10W
Operating temperature: -35°C - +70°C
Dimensions/weight: 183 x 160 x 50mm/1.5kg
